2.5 Ton Telehandler
FT25
Merkmale
Full Remote-Control Operation for Safe and Effortless Mowing
All functions including forward, reverse, turning, lifting, and speed control are operated by full remote control, allowing safe operation in dangerous, steep, or hard-to-reach areas while significantly reducing operator labor intensity.
High-Efficiency Gasoline Power for Stable Cutting Performance
Powered by a 16HP gasoline engine, the machine delivers stable cutting power for dense grass and uneven terrain, ensuring continuous and reliable mowing performance in field and roadside environments.
Self-Charging Electric Power System for Continuous Operation
The built-in generator automatically recharges during operation, reducing downtime and ensuring longer working cycles without frequent external charging interruptions, improving overall jobsite efficiency.
Compact Design for Narrow and Complex Terrain Access
With a compact 1100×1200×580mm structure and 233kg lightweight body, the machine can easily access narrow spaces, slopes, orchards, and complex landscapes where traditional mowers cannot operate.
Strong Terrain Adaptability with Tank-Style Chassis and Narrow Tracks
The 150mm crawler track combined with a tank-style chassis design provides strong ground grip and stability, ensuring smooth operation on muddy, uneven, and sloped terrains with improved climbing capability.
Advanced Drive System with Brushless Motor and Planetary Gear Technology
Equipped with a brushless motor and patented planetary gearbox, the system ensures efficient power transmission, smoother operation, and improved durability under continuous heavy-duty mowing conditions.
Optional Smart Expansion for Precision and Automation Upgrades
Optional GPS functionality allows future smart upgrades for precision mowing management, improving operational efficiency and supporting intelligent landscaping and agricultural applications.
SPEZIFIKATIONEN
| Engine | Engine Type | — | Diesel |
| Engine Model | — | YN28G | |
| Rated Power | kW | 55 | |
| Horsepower | hp | 75 | |
| Number of Cylinders | — | 4 | |
| Engine Brand | — | Yunnei | |
| Emission Standard | — | China Stage II | |
| Equipment Parameters | Overall Dimensions (L × W × H), Excluding Forks | mm | 3950 × 1950 × 1980 |
| Operating Weight | kg | 5500 | |
| Fork | Fork Dimensions (L × W × T) | mm | 1220 × 125 × 45 |
| Lifting | Maximum Lifting Capacity | kg | 2500 |
| Maximum Lift Height | mm | 6000 | |
| Forward Reach at Maximum Lift Height | mm | 1500 | |
| Reach | Maximum Forward Reach | mm | 3000 |
| Chassis | Front Track | mm | 1725 |
| Wheelbase | mm | 2350 | |
| Overall Length to Front Tires | mm | 3450 | |
| Overall Length to Front Carriage | mm | 5170 | |
| Ground Clearance | mm | 250 | |
| Outside Turning Radius (Over Tire) | mm | 8000 | |
| Carriage | Carriage Rollback Angle | ° | 28 |
| Carriage Dump Angle | ° | 33 | |
| Capacities | Fuel Tank Capacity | L | 45 |
| Hydraulic Oil Tank Capacity | L | 100 | |
| Travel | Maximum Travel Speed | km/h | 20 |
| Tires | Tire Size | — | 23.5/70-16 |
| Number of Tires | pcs | 4 | |
| Cab | Cab Interior Width | mm | 820 |
| Air Conditioning | — | Yes | |
| Steering | Steering System | — | Yes |
*HINWEIS: Spezifikationen und Konfigurationen können sich aufgrund kontinuierlicher Produktaktualisierungen und -verbesserungen ohne vorherige Ankündigung ändern. Alle Angaben dienen lediglich als Referenz, einige Funktionen sind optional. Bitte kontaktieren Sie unser internationales Vertriebsteam zur Bestätigung. Die endgültigen Spezifikationen und Konfigurationen unterliegen dem von beiden Parteien unterzeichneten Vertrag.
